Ultrasonic Thickness Gage26MG
Description
26 MG
- 초음파를 이용하여 재질의 두께 측정, 내부 결함, 부식 유무 및 라미네이션의 존재를 측정할 수 있는 휴대용 초음파 장비
- 현장 사용에 적합한 가벼운 포켓 사이즈
- 고온측정 가능
- 위험지역 측정인증장비(MIL-STD-810E, method 511.3, procedure 1)
Panametrics 26MG Specifications*
| Measurement Mode: Pulse echo with dual element transducers |
| ThicknessMeasurement Range: 0.020 to 19.999″ (0.50 to 508 mm) Note: Thickness range depends on material, transducer type, surface condition, and temperature. |
| MaterialVelocity Calibration Range: 0.0300-0.5511 in/µsec (0.762- 13.999 mm/µsec) Thickness Display Resolution: LOW: 0.01″ 0.1 mm STANDARD: 0.001″ 0.01 mm |
| Measurement Rates: Standard Rate: 4 per second |
| Fast Rate: 20 per second |
| Fast Min Mode: Rapid capture and recall of minimum thickness at Fast Rate of 20 per second. |
| Freeze Mode: Freezes display to instantly capture critical thickness. Minimizes transducer couplant lift-off error and facilitates high temperature measurements. |
| Automatic Probe Recognition: Automatically recognizes the listed Panametrics-NDT transducer types. Adjusts internal parameters and corrects V-path error. |
| Zero Compensation Mode: Compensates for transducer temperature and zero offset. |
| Display: 4 1/2 digit (19999 counts) Liquid Crystal Display (LCD), 0.4″ (10.2 mm) numerals |
| Display Hold/Blank Mode: Display holds or blanks after measurement. |
| Electroluminescent Display Back Lighting: Selectable as “On” or “Auto On” |
| Receiver Bandwidth: 1-15 MHz (-3dB) |
| Metric/English Mode: Metric or English units |
| Battery: 2 AA Alkaline Batteries |
| Operating Time: 250 hours typical battery life; 30 hours continuous with backlight on |
| Low Battery Indicator: Continuously indicates battery status |
| BatterySaver: Auto Power Off/Continuous On |
| Case/Keypad: Splash proof, impact-resistant Lexan® case. Sealed, color-coded keypad with tactile and audible feedback. |
| Operating Temperature Range:-10° C to +50° C, 14° F to 122° F |
| Size: 2.55″ W x 5.05″ L x 1.14″ H(64.8 mm x 128.7 mm x 29 mm) |
| Weight: 8.5 oz. (0.24 kg) |
| Hazardous Area Operations: As defined by MIL-STD-810E, method 511.3, procedure 1. |
| *All specifications subject to change without notice. |
